BMW 3 series touring (G21), engines and dimensions

THE 3

BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Touring.

Read more
THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

BMW 3 SERIES TOURING: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1.645
Max. permissible weight in kg 2,135
Permitted load in kg 565
Permitted axle load front/rear in kg 975/1,260
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,510
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11

Performance

Top speed in km/h 230
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 7.5

Fuel consumption

Urban in l/100 km 7.8
Extra-urban in l/100 km 6.0
Combined in l/100 km 6.7
CO2 combined emissions in g/km 152
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (HP) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (HP) -
Combined torque Nm -

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 330i Touring:
Fuel consumption in l/100 km (combined): 7,7–6,8
CO2 emissions in g/km (combined): 176–155



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

Fuel consumption and CO2 emissions.

  • BMW 330i Touring:
    Fuel consumption in l/100 km (combined): 6.9
    CO2 emissions in g/km (combined): 157

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
