BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Touring.
THE 5BMW 5 SERIES TOURING: ENGINES & TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Touring.
BMW 5 SERIES TOURING: TECHNICAL DATA.
Select model
- BMW 530i Touring
No search result found. Please try another input
| Unladen weight EU in kg | 1,805 |
|---|---|
| Max. permissible weight in kg | 2,425 |
| Permitted load in kg | 695 |
| Permitted axle load front/rear in kg | 1,120/1,430 |
| Luggage capacity min. (seats up or roof down) in l | 560 |
| Luggage capacity max. (seats down or roof up) in l | 1,700 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,000 |
| Trailer load 12% (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in hp at 1/min | 252/5,200-6,500 |
| Engine torque (Nm) at 1/min | 350/1,450-4,800 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 6.7 |
| Top speed electrical in km/h | - |
| Urban in l/100 km | 11.7 |
|---|---|
| Extra-urban in l/100 km | 16.1 |
| Combined in l/100 km | 14.1 |
| CO2 combined emissions in g/km | 162 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 68 |
| Tyre dimensions front | 225/55 R17 97 Y |
|---|---|
| Tyre dimensions rear | 225/55 R17 97 Y |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium-ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (PS) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (PS) | - |
|---|---|
| Combined torque Nm | - |
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW 530e** Touring:
Fuel consumption in l/100 km (combined): 1.9–1.5
CO2 emissions in g/km (combined): 43–35
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
