BMW X3: Technical Data

Technical Data of the BMW X3

Select model


Unladen weight EU in kg 1,735
Max. permissible weight in kg 2,330
Permitted load in kg 670
Permitted axle load front/rear in kg 1,070/1,370
Luggage capacity min. (seats up or roof down) in l 550
Luggage capacity max. (seats down or roof up) in l 1,600
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000


Cylinders/valves 4/4
Capacity in ccm 1,597
Stroke/bore in mm 75.6/82.0
Engine power in kW (HP) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0


Top speed in km/h 208215
Acceleration 0–100 km/h in s 8.2

Fuel consumption

Urban in l/100 km 8.2
Extra-urban in l/100 km 6.5
Combined in l/100 km 7.1
CO2 combined emissions in g/km 163
Tank capacity, approx. in l 61/65


Tyre dimensions front 245/50 R19
Tyre dimensions rear 245/50 R19
Wheel dimensions and material front 7.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 19 inches, light-alloy

Information about the data.

  • BMW X3 sDrive20i:
    Fuel consumption in l/100 km (combined): 7.1
    CO2 emissions in g/km (combined): 163

    The fuel consumptions and CO2 emissions figures shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown consider the different size of the selected wheels and tires.

    The values for the BMW X3 xDrive20i and the BMW X3 xDrive30i are already based on the new WLTP regulation and are translated back into NEDC-equivalent values in order to ensure the comparison between the vehicles. With respect to these vehicles, for vehicle related taxes or other duties based (at least inter alia) on CO2 emissions the CO2 values may differ to the values stated here depending on national legislation.

    The values for the BMW X3 xDrive20i and the BMW X3 xDrive30i are provisional figures.

    Unladen weight (EU) in kg: the figure quoted includes a 90 % tank filling, 75 kg for the. Unladen weight applies to vehicles with standard equipment. Optional equipment may increase this figure.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the Pkw-EnVKV and based on the fuel consumption and CO2 values according to the NEDC cylce for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at
