TECHNICAL DATA FOR THE BMW 5 SERIES SEDAN.
|
Powertrain type |
Electric |
|---|---|
|
Power in kW (hp) |
250 (340) |
|
Torque in Nm |
430 |
|
Transmission |
1-speed, automatic |
|
Drivetrain |
Rear-wheel drive |
|
(Nominal) power/30-minutes-power in kW (hp) |
250 (340) |
|---|
|
Acceleration 0–100 km/h in s |
6 |
|---|---|
|
Electric top speed in km/h |
193 |
| 1 | |
|---|---|
|
CO2 emissions, combined WLTP in g/km |
0 |
|
Energy consumption, combined WLTP in kWh/100 km |
18.9 - 15.9 |
|
Electric range, WLTP in km 2 |
498 - 582 |
| 3 | |
|---|---|
|
Battery capacity in kWh |
81.2 |
|
Added range after 10 minutes of high-power charging (HPC) in km 3 |
156 |
|
Maximum charging power AC in kW |
11 (-) |
|
Minimum charging time AC 0–100% state of charge in h |
8.5 |
|
Maximum charging power DC in kW |
205 |
|
Minimum charging time DC 10 - 80% state of charge in min |
0:30 |
|
5,060 mm
|
|
|
1,900 mm
|
|
|
1,515 mm
|
|
|
Length in mm |
5,060 |
|
Width in mm |
1,900 |
|
Height in mm |
1,515 |
|
Width incl. mirrors (driver / passenger side) in mm |
2,156 (1,081 / 1,075) |
|
Wheelbase in mm |
2,995 |
|
Vehicle curb weight in kg 4 |
2,205 |
|
Payload in kg |
610 |
|
Luggage capacity in l |
490 |
|
Powertrain type |
Electric |
|---|---|
|
Power in kW (hp) |
442 (601) |
|
Torque in Nm |
795 |
|
Transmission |
1-speed, automatic |
|
Drivetrain |
All-wheel drive |
|
(Nominal) power/30-minutes-power in kW (hp) |
127 (170)/- |
|---|---|
|
(Nominal) torque in Nm |
795 |
|
Acceleration 0–100 km/h in s |
3.8 |
|---|---|
|
Top speed in km/h |
230 |
| 1 | |
|---|---|
|
Energy consumption, combined WLTP in kWh/100 km |
18.2 - 20.6 |
|
Electric range, WLTP in km 2 |
455 - 516 |
| 3 | |
|---|---|
|
Battery capacity in kWh |
81.2 |
|
Added range after 10 minutes of high-power charging (HPC) in km 3 |
186 |
|
Maximum charging power AC in kW |
11 |
|
Minimum charging time AC 0–100% state of charge in h |
22 |
|
Maximum charging power DC in kW |
205 |
|
Minimum charging time DC 10 - 80% state of charge in min |
0:30 |
|
5,060 mm
|
|
|
1,900 mm
|
|
|
1,505 mm
|
|
|
Length in mm |
5,060 |
|
Width in mm |
1,900 |
|
Height in mm |
1,505 |
|
Wheelbase in mm |
2,995 |
|
Vehicle curb weight in kg 4 |
2,380 |
|
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg 5 |
2,000/- |
|
Luggage capacity in l |
490 |
| 6 | |
|---|---|
|
Powertrain type |
Petrol – 48 Volt Mild-Hybrid |
|
Power in kW (hp) |
140 (140) 7 |
|
Torque in Nm |
310 7 |
|
Transmission |
8 - speed, automatic |
|
Drivetrain |
Rear-wheel drive |
| 6 | |
|---|---|
|
Cylinders |
4 |
|
Displacement in cm3 |
1,998 |
|
Nominal power in kW (hp)/1/min |
140 (190) |
|
Nominal torque in Nm/1/min |
310 / 1,500 - 4,000 |
|
(Nominal) power/30-minutes-power in kW (hp) |
8 (11) |
|---|
|
Acceleration 0–100 km/h in s |
8.1 |
|---|---|
|
Top speed in km/h |
193 |
| 3 | |
|---|---|
|
Battery capacity in kWh |
0,9 |
|
5,060 mm
|
|
|
1,900 mm
|
|
|
1,515 mm
|
|
|
Length in mm |
5,060 |
|
Width in mm |
1,900 |
|
Height in mm |
1,515 |
|
Width incl. mirrors (driver / passenger side) in mm |
2,156 (1,081/1,075) |
|
Wheelbase in mm |
2,995 |
|
Vehicle curb weight in kg 4 |
1,800 |
|
Payload in kg |
610 |
|
Luggage capacity in l |
520 |
|
Tank capacity in l |
60 |
Fuel consumption and CO2 emissions.
BMW 520i sDrive: Fuel consumption, combined WLTP in l/100 km: 6,4–5,7; CO2 emissions, combined WLTP in g/km: 144–130
Provided technical data are measured according to the WLTP, not NEDC
